Chi Tiết Sản Phẩm

DS-7616NXI-K2/S

Đầu ghi hình Acusense
Hỗ trợ tính năng so sánh khuôn mặt, chụp hình khuôn mặt, tìm kiếm khuôn mặt; hỗ trợ thư viện đến 10.000 khuôn mặt;
Hỗ trợ 4 kênh báo động so sánh khuôn mặt; 1 kênh chụp hình khuôn mặt;
Hoặc 4 kênh phân biệt người và phương tiện;
Hỗ trợ camera độ phân giải đến 8MP;
H.265+/H.265/H.264+/H.264

THÔNG SỐ KỸ THUẬT
BÌNH LUẬN

Model	DS-7608NXI-K2/S	DS-7616NXI-K2/S
Facial Recognition¹
Facial detection and analytics	Face picture comparison, human face capture, face picture search
Face picture library	Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)
Face picture comparison	4-ch face picture comparison alarm
Performance of facial detection and analytics	1-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)
Perimeter Protection¹
Human/Vehicle analysis	Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total
Video and Audio
IP video input	8-ch	16-ch
	Up to 8 MP resolution
Incoming bandwidth	80 Mbps	160 Mbps
Outgoing bandwidth	256 Mbps
HDMI output	1-ch, 4K (3840 × 2160)/30Hz, 2K(2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA output	1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video output mode	HDMI/VGA independent output
Audio output	1-ch, RCA (Linear, 1 KΩ)
Two-way audio input	1-ch, RCA (2.0 Vp-p, 1 KΩ)
Decoding
Decoding format	H.265+/H.265/H.264+/H.264
Recording resolution	8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback	8-ch	16-ch
Capability	2-ch@8 MP(25fps) /4-ch@4MP(30fps) /8-ch@1080p(30fps)
Stream type	Video, Video & Audio
Audio compression	G.711ulaw/G.711alaw/G.722/G.726/MP2L2
Network
Remote connections	128
Network protocol	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network interface	1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Auxiliary interface
SATA	2 SATA interfaces
Capacity	Up to 8 TB capacity for each disk
Alarm in/out	4/1
USB interface	Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
General

Power supply	12 VDC
Consumption (without HDD)	≤ 30 W
Working temperature	-10 °C to 55 °C (14 °F to 131 °F)
Working humidity	10% to 90%
Chassis	1U chassis
Dimension (W × D × H)	385 × 315 × 52 mm ( 15.2″× 12.4″ × 2.0″)
Weight (without HDD)	≤ 1.8 kg (4 lb.)
Certification
FCC	Part 15 Subpart B, ANSI C63.4-2014
CE	EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
